Advantages and Features:

◆ High-frequency design, high power density, compact size, and high overall efficiency;

◆ Bidirectional energy storage design enables bidirectional energy flow control, allowing both photovoltaic and mains power to charge the battery;

◆ Ultra-wide MPPT range, down to 40Vdc (24V model) / 80Vdc (48V model);

◆ Configurable operating mode (grid-connected, off-grid, and hybrid);

◆ Grid-connected current setting function;

◆ Output priority setting function;

◆ Charging priority setting function;

◆ Lithium battery BMS communication function;

◆ Supports battery-free operation mode;
